Quarterly Display Capex and Equipment Market Share Report

Report Summary

メールお問い合わせ ⇒ 和文概要資料&商品サンプルをご返信します。国内アナリストによる詳細解説もお申し付けください。 This report includes all of DSCC's content on OLED and LCD fab schedules, OLED and LCD capacity and LCD and OLED equipment market sizes, market share and forecasts for 79 different segments. All design wins and units by fab by equipment type are shown and quarterly revenues are provided for >130 different display equipment suppliers. Also included are typical process flows for each major process.


  • File Format

    PDF式 (レポート本体編) & Excel式 (データベース編)
  • Published

    季刊
  • Order Report

【ご検討者様へのご案内】
1) まずは「お問い合わせフォーム」でのご連絡にて、和文概要資料、商品サンプル、国内販売価格をご返信します。2) その後、国内アナリストによる「本レポートの強み~DSCC独自の分析手法とは」の詳細ご説明の上、お客様のミッションやお悩みをお聞かせください (WEB面談) 。本レポートを主候補に、課題解決に向けた最適サービスをご提案させていただきます。 3) ご購入後も、掲載内容に関するご質問を国内お客様サポート窓口が承り、国内外アナリスト/コンサルタントとの交流をお手伝いします。

※以下はグローバルサイトのご紹介情報です。最新号の掲載内容を「お問い合わせフォーム」からご確認ください。

This report provides all of the market intelligence that a display equipment manufacturer, supplier to display equipment manufacturer or analysts covering display equipment suppliers would want. It is also ideal for panel suppliers tracking the market shares for all major display equipment segments. In total, 79 different equipment segments have been covered compared to 22 from other research firms.. Market share and design wins are provided for every segment as well on a quarterly, annual, billings and bookings basis, while other research firms don't offer any market share data.

Deliverables include:

  • OLED Fab Schedules and Capacity Forecast;
  • LCD Fab Schedules and Capacity Forecast;
  • OLED equipment market size by segment and forecasted out to 2024;
  • LCD equipment market size by segment and forecasted out to 2024;
  • Equipment revenues on a bookings or billings basis;
  • Equipment revenues on a move-in or install (sign-off) basis;
  • Quarterly and annual equipment market share provided from 2016 to as far as 2024 for all backplane, frontplane, color filter, cell and most module segments.
  • Design wins and units by supplier for all backplane, frontplane, color filter, cell and most module segments;
  • Market share on a quarterly, annual, bookings and billings basis for over 70 different segments;
  • Equipment prices for over 70 different tool segments​​ by generation.

Segments Covered in the Q3'20 Report Include:

  • Backplane
    • AOI
    • Array Test
    • Automation
    • Bubble/PI Other Repair
    • CD/Overlay
    • Coater/Developer
    • CVD
    • Dry Etch
    • Dry Strip
    • ELA
    • Exposure
    • Film Thickness Measurement
    • Furnace (Activation/Annealing)
    • Ion Implant
    • ITO Furnace
    • Laser CVD Repair
    • O/S Tester
    • Other Backplane
    • PI Coater
    • PI Curing
    • PVD - ITO/IGZO
    • PVD - S/D, Gate, L/S
    • SEM
    • Total Pitch
    • Wet Clean
    • Wet Etch - Gate, S/D
    • Wet Etch - ITO/IGZO
    • Wet Strip
    • Zap Repair
  • Frontplane
    • AOI
    • Automation
    • CD/Overlay
    • Evaporation (R&D)
    • Film Thickness Cluster
    • Film Thickness (stand-alone)
    • FMM VTE
    • FMM VTE Source
    • Frontplane Automation
    • Glass/Metal Encapsulation
    • Half cut glass cut
    • IJP
    • Inorganic TFE
    • Laser Drilling
    • LLO
    • Open Mask VTE
    • Open Mask VTE Source
    • Organic TFE
    • Other Frontplane
    • Total Pitch
  • Color Filter
    • AOI
    • Automation
    • CD/Overlay
    • Coater
    • Developer
    • Exposure
    • Other
    • Laser Repair
    • Tape/Ink Repair
    • Sputtering
    • Total Pitch
  • Cell
    • LC Insertion
    • Photo Alignment
    • PI Coating
    • PI Curing
    • PI IJP
    • Rubbing
    • Seal Dispense
    • Vacuum Alignment
    • Automation
    • Other Cell
  • Module
    • Automated Module Test
    • Automated Final Test
    • Automated Cell Aging Test
    • Cell/Module Repair
    • COF/COP/COG Bonding
    • FOF/FOG Bonding
    • Lamination
    • Laser Cell Cutting
    • Laser Shape Cutting
    • ​Multi Time Program Test
    • Scribe
    • Visual Inspection
    • Other Module

Table of Contents

  • Page 3 - Executive Summary
  • Page 13 - Methodology and Process Overview
  • Page 36 - Fab Schedules and Discussion
  • Page 45 - Display Equipment Spending
  • Page 83 - Supplier Market Share by Equipment Segment
    • Page 86 - TFT Backplane Supplier Share by Segment
    • Page 115 - OLED Frontplane Supplier Share by Segment
    • Page 135 - Color Filter Supplier Share by Segment
    • Page 147 - Cell Supplier Share by Segment
    • Page 158 - Module Supplier Share by Segment
  • Capacity - Separate Deliverable
